Blade Parameter Size
Blade MAC2 MAC3 MAC4
Application Small Adult Adult Large Adult
Intubation Inner Diameter 5.0-6.0mm 6.0-9.0mm 7.0-10.0mm
Length 12.11 14.25 16.08
Sterilize 2.0% Glutaral fully soak for 10 minutes OR 0.5% Cidex OPA for more than 5 minutes
Technical Specication
Parts Description Technical Index
Machine Display 3inch LCD
Resolution 640*480 (RGB)
Viewing Angle ≥60°
Power <2W
Display Front/Back Rotation Angle 0°-130°
Weight 225g
Camera Illuminance ≥150 LUX
Resolution 1280*720 px
Image/Video Function Image/Video Function Yes
Output USB output, Easy to storage & establish image/video
Memory Type SD card 8GB
Battery Battery Type Rechargable Lithium battery
Capacity 1350mAh
Cycle Life of Battery >500times
Battery Working Time >240min
Charging Time <2(hrs)
